Nov. 03, 2021
Thermistors are widely used. LED lights, mobile phones, computers, refrigerators, electronic thermometers, vacuum cleaners and other electronic devices in life are all equipped with thermistors to prevent overheating of the devices. This article will tell you what we should pay attention to when measuring the thermistor.
The role of NTC thermistor:
For negative temperature coefficient (NTC) thermistor, the resistance value will change with the temperature change of 3~5%/℃. It is often used as a general temperature sensor in electronic equipment. For example, a smart phone uses a negative temperature coefficient (NTC) thermistor to measure the temperature inside the smart phone, and then uses this temperature information to control the temperature.
Matters needing attention in measuring thermistor:
1. Do not touch the components and circuit boards during the measurement, because your body temperature will affect the measurement results. Try to avoid breathing into the module and restrict the air flow near the module.
2. The NTC thermistor should be placed near the measurement area. If the thermometer is far away from the measurement area, the temperature of the measurement area may be different from the temperature of the thermometer.
3. Refer to the resistance and temperature table, and pay attention to the specific value of the measured temperature.
4. Since it is difficult to make high-accuracy measurements in the air, it is recommended to measure the resistance value in a liquid bath to ensure high accuracy.
The above are things needed to be paid attention to when measuring a thermistor. Hopefully the content of this article is helpful to everyone. Dongguan Zhixu Electronic Co., Ltd. (also JYH HSU(JEC)) has a full range of varistor and capacitor models. JEC has passed ISO9001:2015 quality management system certification; JEC safety capacitors (X capacitors and Y capacitors) and varistors have passed national certifications of the main industrial powers across the world; JEC ceramic capacitors, film capacitors and super capacitors are in compliance with environmental protection indicators. Welcome to contact us for free samples and any questions.
